Hoshizaki F-801MWJ, Flaker Icemaker, Water-cooled

Name: Hoshizaki F-801MWJ, Flaker Icemaker, Water-cooled
Brand: Hoshizaki
SKU: F-801MWJ
Price: 7188.5 USD
Availability: InStock

by Hoshizaki

$7,188.50 - $7,188.50

$7,188.50

$7,188.50 - $7,188.50

$7,188.50

Quantity

More payment options

Delivery time

5-8 Business Days

Secure Checkout

Secure online checkout. We do not store customer payment data.

Business Hours: 9 AM - 5 PM CST

Phone: (409) 248-2480

Email: hi@globalmina.com

From The Manufacturer

The F-801MWJ is capable of producing approximately 680 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Water-cooled, Slim Line Modular icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-801MWJ requires a Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Specifications

Dimensions: 22″ W x 27-3/8″ D x 26″ H
Up to 680 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces flaked ice
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1150, B-1300, B-1500, B-1650
2 second rinse every hour to remove sediment for cleaner ice
Advanced CleanCycle24™ design
Infrared bin control for easy cleaning and reliability
R-404A refrigerant (10.6 oz. / 300 g)
Heat Rejection: BTU/hr
Ambient temperature range: 45 – 100°F
Water temperature range: 45 – 90°F
Water pressure: 10 – 113psig
Voltage range: 104 – 127V
11.8 amps (15 Amp Max fuse)
3.9 kwh/100 lbs.@ 90/70
Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included
Infrared bin control for easy cleaning and reliability
Three Years: Parts & Labor warranty on entire machine.
Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Additional information

Weight	200 lbs
Dimensions	X X in
Warranty	\|Three Years: Parts & Labor warranty on entire machine.\|\|
Electrical Specs:	Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 11.8, Max Fuse/HACR Breaker: 15 A
Plumbing Specs:	1/2" FPT Inlet, Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent, 3/8" FPT Outlet, Minimum 1/4" Nominal ID Hard Pipe or Equivalent, Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent
Utility Consumption:	3.9 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating Limits:	Ambient Temp Range: 45 - 100°F, Water Temp Range: 45 - 90°F, Water Pressure: 10 - 113psig, Voltage Range: 104 - 127V, Heat Rejection: BTU/hr, Refrigerant Charge: R-404A, (10.6 oz. / 300 g)

Service Literature

Video

Shipping

FREE GROUND SHIPPING

Ships to: Lower 48 United States
Ships via: FedEx, UPS, or Motor Freight
Standard 5-8 Day Shipping
All orders after 3pm CST will be processed the following day

Once your order is placed, we will pre-authorize your credit card and you should receive a confirmation that your item has shipped within 5-7 business days with a tracking number. In the event there will be a delay we will reach out to you with a timeline. If you do not hear from us within that time please email us at hi@globalmina.com.

Expedited Shipping is available upon request and may be subject to additional costs.
